1200mm Reach 6kg Payload Intelligent Joint Stamping Robot

The 6 kg payload, 6‑axis stamping robot from FUXIN is designed to meet the needs of high-speed, high-precision metal stamping automation. Featuring intelligent joint control, a compact footprint, and wide arm reach, it is ideal for small and medium-sized stamping tasks in automotive, appliance, and electronics industries.

This industrial stamping robot is specifically designed for press machines with a tonnage of 110T and below, a press center distance below 2200mm.

(1) Flexible configurations of 3-axis, 4-axis, and 5-axis, providing you with more operational choices.

(2) Suitable for grabbing products with sizes up to 400x400mm.

(3) Ideal for stamping sites handling small electronic products, home appliance parts, and mechanical components.

Inquire Now

Parameter

6kg Stamping Robot Overview

Typical Applications

Automatic loading/unloading in press lines
Multi-die stamping workflows
Sheet metal part handling and forming
Small metal parts transfer and positioning
Ideal for automotive interiors, electrical components, and appliance housing production

Typical Applications

Precision stamping of small‑scale metal parts
Integration with press machines for automatic loading/unloading
Material handling, stacking, and palletizing lines
Industrial sectors: electronics, automotive, appliances, medical devices

Key Advantages

High Precision: ±0.03 mm repeatability ensures superior stamping accuracy.
Extended Reach: 1200 mm arm reach covers large working envelopes and multiple dies.
Flexible Mounting: Supports both floor and upside-down installations.
Lightweight & Compact: Only 40 kg, easy to integrate into existing lines.
Intelligent Control System: Delivers responsive, coordinated multi-axis motion.
Versatile I/O Communication: Easily connects with other automation devices.

Model No.		QF-1206 *4-axis, 5-axis are available
Machine Voltage		AC 220V ±10％
Machine Frequency		50/60 Hz
Machine Power		3.5 KW
Ambient temperature during operation		-20℃～45℃
Ambient humidity during operation		20%～80%
Max. Reach		1200 mm
Min. Reach		250 mm
Pose Repeatability		±0.1 mm
Payload		6 KGS
Axis Motion Range	Axis J1	±160°
	Axis J2	-25°～+75°
	Axis J3	-65°～+75°
	Axis J4	±300°
	Axis J5	±360°
Axis Velocity	Axis J1	259.2°/S
	Axis J2	257.1°/S
	Axis J3	223.1°/S
	Axis J4	337.5°/S
Machine Weight		≈138 kg

Feel free to reach out to FUXIN sales team for more information.

We are here to assist you in finding the right solution for your automation requirements.
